xWDM type DWDM
Channel number 8
Supported channels 34,35,36,37,38,39,40,41
Multiplexer type MUX/DEMUX
Upgrade port 1 14 – 32 and 43 – 61
Monitor port 1
Connector type LC/UPC
Length mm 215
Height mm 20
Depth mm 213
weight 0,32
Operating temperature -5|70
Transmission type Duplex
Mounting type Chassis
Chassis type GBC Drawer
Insertion Loss ˂3.5 dB
Return Loss ˃45 dB
8+1 channels Duplex DWDM Mux/Demux in „drawer”, 8 DWDM channels: 34-41 + UPG port and MONITOR Port

Duplex multiplexer with 8 DWDM ports and single upgrade port

GBC Photonics has passive multiplexers which allow to increase capacity of optical cables by adding multiple transmissions. Thanks to top-notch CWDM filters multiplexers have low insertion loss and high channel isolation. Drawer housing allow to save space, using dedicated chassis we can place up to 4 drawer devices in 1U.

GPDMD081LULU3441MDSS Multiplexer allows to launch 8 transmissions in DWDM technology using a pair of fibers and with upgrade port we can easily expand capabilities of device. Multiplexer has LC/UPC ports and built-in monitor port which allows to check upstream and downstream power on working transmissions.

Ports

8 ports LC/UPC on DWDM channels 34 - 41, Upgrade port LC/UPC, monitor port LC/UPC, line port LC/UPC

Monitor Port

Built-in monitor port allows to check 1% of upstream and downstream power

Upgrade Port

Single Upgrade ports for DWDM channels 14 - 32 and 43 - 61

Drawer housing

Drawer housing, ensure to save space and elegant design
