xWDM type DWDM
Channel number 8
Supported channels 34,35,36,37,38,39,40,41
Multiplexer type MUX
Upgrade port 1 14 – 32 and 43 – 61
Monitor port 1
Connector type SC/APC
Length mm 215
Height mm 20
Depth mm 213
weight 0,32
Operating temperature -5|70
Transmission type Simplex
Mounting type Chassis
Chassis type GBC Drawer
Insertion Loss ˂3.5 dB
Return Loss ˃45 dB
8+1 channels Simplex DWDM Mux in „drawer”, 8 DWDM channels: 34-41 + UPG port and MONITOR Port

Simplex multiplexer with 8 DWDM ports and single upgrade port

GBC Photonics has passive multiplexers which allow to increase capacity of optical cables by adding multiple transmissions. Thanks to top-notch CWDM filters multiplexers have low insertion loss and high channel isolation. Drawer housing allow to save space, using dedicated chassis we can place up to 4 drawer devices in 1U.

GPDMS081SASA3441MDSS Multiplexer allows to launch 8 transmissions in DWDM technology using a single of fiber and with upgrade port we can easily expand capabilities of device. Multiplexer has SC/APC ports and built-in monitor port which allows to check upstream and downstream power on working transmissions.

Ports

8 ports SC/APC on DWDM channels 34 - 41, Upgrade port SC/APC, monitor port SC/APC, line port SC/APC

Monitor Port

Built-in monitor port allows to check 1% of upstream and downstream power

Upgrade Port

Single Upgrade ports for DWDM channels 14 - 32 and 43 - 61

Drawer housing

Drawer housing, ensure to save space and elegant design
