xWDM type DWDM
Channel number 16
Supported channels 21,22,23,24,25,42,43,44,45,46,47,48,49,18,19,20
Supported wavelengths 1470-1490
Multiplexer type MUX/DEMUX
Monitor port 1
Connector type LC/UPC
Length mm 215
Height mm 40
Depth mm 213
weight 0,32
Operating temperature -5|70
Transmission type Simplex
Mounting type Chassis
Chassis type GBC Drawer
Insertion Loss ˂3.5 dB
Return Loss ˃45 dB
16 channels Simplex DWDM over 1J ver B Mux in „drawer”, 16 DWDM channels: 42-49 and 18-25, MONITOR Port, channel OSC

Simplex multiplexer with 16 DWDM channels, type B

GBC Photonics has passive multiplexers which allow to increase capacity of optical cables by adding multiple transmissions. Thanks to top-notch DWDM filters multiplexers have small insertion loss and high channel isolation. Drawer housing allow to save space, by using dedicated chassis we can place up to 2 drawer devices in 1U.

GPDMS080LULU1849MDSS-B Multiplexer allows to launch 8 transmissions in DWDM technology by using a single fiber. Device has 16 DWDM channels 18 to 25 for receive and 42 to 49 for transmit. Multiplexer has LC/UPC ports and built-in monitor port due to which we are able to check power on each channel.

Ports

16 ports LC/UPC on DWDM channels 18 - 25 and 42 - 49, monitor port LC/UPC, line port LC/UPC

Monitor Port

Built-in monitor port allows to check 1% of upstream and downstream power

Drawer housing

Drawer housing, ensure to save space and elegant design
