Channel number 2
Monitor port 1
Connector type LC/UPC
Length mm 432
Height mm 43
Depth mm 245
weight 0,8
Operating temperature -5|70
Transmission type Duplex
Mounting type 19'' Rack
Chassis type 1U 19"
OTDR port 0
OADM type East & West
2 channels Duplex DWDM OADM, East&West in 19” 1U Rack, 2 DWDM channels: xx, MONITOR Port, LC/UPC connectors

Duplex OADM East&West with 2 DWDM channels

GBC Photonics has passive OADMs which allow to increase capabilities of network by adding and dropping specific transmissions in intermediate nodes. Thanks to top-notch DWDM filters OADMs have small insertion loss and high channel isolation.

GPDOD020LULUxxxxMRSS OADM allows to add transmissions in DWDM technology, two in East direction and West by using a pair of fibers. OADM type East and West can add transmission in both directions. Device has LC/UPC ports and built-in monitor port which allows to check upstream and downstream power on working transmissions. Rack housing allows to mount it in standard 19" cabinet.

Ports

4 ports LC/UPC on DWDM channel xx, port East LC/UPC, port West LC/UPC, monitor ports LC/UPC

Monitor Port

Built-in monitor port allows to check 1% of upstream and downstream power
