xWDM type DWDM
Channel number 8
Supported channels 34,35,36,37,38,39,40,41
Multiplexer type DEMUX
Monitor port 1
Connector type SC/APC
Length mm 215
Height mm 20
Depth mm 213
weight 0,32
Operating temperature -5|70
Transmission type Simplex
Mounting type Chassis
Chassis type GBC Drawer
Insertion Loss ˂3.5 dB
Return Loss ˃45 dB
8 channels Simplex DWDM Demux in „drawer”, 8 DWDM channels: 34-41+ MONITOR Port

Simplex demultiplexer with 8 DWDM ports

GBC Photonics has passive multiplexers which allow to increase capacity of optical cables by adding multiple transmissions. Thanks to top-notch DWDM filters multiplexers have low insertion loss and high channel isolation. Drawer housing allow to save space, using dedicated chassis we can place up to 4 drawer devices in 1U.

GPDDS080SASA3441MDSS Demultiplexer allows to launch 4 transmissions in DWDM technology using a single fiber. Demultiplexer has SC/APC ports and built-in monitor port which allows to check downstream power on working transmissions.

Ports

8 ports SC/APC on DWDM channels 34 - 41, monitor port SC/APC, line port SC/APC

Monitor Port

Built-in monitor port allows to check 1% of downstream power

Drawer housing

Drawer housing, ensure to save space and elegant design
