xWDM type CWDM
Channel number 8
Supported wavelengths 1370,1390,1410,1430,1450,1470,1590,1610,GPON,CATV
Multiplexer type MUX
Upgrade port 1 1503 ~ 1577 nm
Connector type SC/APC
Length mm 215
Height mm 20
Depth mm 213
weight 0,32
Operating temperature -5|70
Transmission type Simplex
Mounting type Chassis
Chassis type GBC Drawer
Insertion Loss ˂3.5 dB
Return Loss ˃45 dB
8 channels Simplex CWDM Mux in „drawer”, 8 CWDM channels: 1370-1470, 1590-1610nm + GPON&CATV with SC/APC connectors

Simplex multiplexer with 8 CWDM ports and ports for GPON and CATV transmission

GBC Photonics has passive multiplexers which allow to increase capacity of optical cables by adding multiple transmissions. Thanks to top-notch CWDM filters multiplexers have low insertion loss and high channel isolation. Drawer housing allow to save space, using dedicated chassis we can place up to 4 drawer devices in 1U.

GPCMS080SASA2761NDSS Multiplexer allows to launch 4 transmissions in CWDM technology using a single fiber and with dedicated ports we can simultaneously send GPON and CATV transmission. Multiplexer has SC/APC ports.

Ports

8 ports SC/APC on CWDM lambdas 1370 - 1470, 1590 and 1610 nm, SC/APC port on GPON and CATV, line port SC/APC

Drawer housing

Drawer housing, ensure to save space and elegant design
