Channel number 1
Supported wavelengths GPON
Connector type SC/APC
Length mm 215
Height mm 20
Depth mm 213
weight 0,32
Operating temperature -5|70
Transmission type Simplex
Mounting type Chassis
Chassis type GBC Drawer
OADM type East only
Simplex OADM GBCPhotonics GPON East Only OADM in "drawer" with SC/APC connectors

Simplex OADM on GPON transmission

GBC Photonics has passive OADMs which allow to increase capabilities of network by adding and dropping specific transmissions in intermediate nodes. Thanks to top-notch CWDM filters OADMs have low insertion loss and high channel isolation. Drawer housing allow to save space, using dedicated chassis we can place up to 4 drawer devices in 1U.

GPCOS001SASAgponNDSS-1 OADM allows to add  GPON transmission, single in East direction using a single fiber. OADM type East only can add transmission only in direction to East port. Device has SC/APC ports.

Ports

1 SC/APC port on GPON transmission, port East SC/APC, port West SC/APC

Drawer housing

Drawer housing, ensure to save space and elegant design
