xWDM type CWDM
Channel number 10
Supported wavelengths 1270-1450
Multiplexer type MUX/DEMUX
Connector type LC/UPC
Length mm 215
Height mm 20
Depth mm 213
weight 0,32
Operating temperature -5|70
Transmission type Duplex
Mounting type Chassis
Chassis type GBC Drawer
Insertion Loss ˂3.5 dB
Return Loss ˃45 dB
10 channels Duplex CWDM Mux/Demux in „drawer”, 10 CWDM channels: 1270-1450nm

Duplex multiplexer with 10 CWDM ports

GBC Photonics has passive multiplexers which allow to increase capacity of optical cables by adding multiple transmissions. Thanks to top-notch CWDM filters multiplexers have low insertion loss and high channel isolation. Drawer housing allows to save space, using dedicated chassis we can place up to 4 drawer devices in 1U.

GPCMD100LULU2745NDSS Multiplexer allows to launch 10 transmissions using a pair of fibers. Device has CWDM filters all in II transmit window. Multiplexer has LC/UPC ports.

Ports

20 ports LC/UPC on CWDM lambdas 1270 - 1450 nm, line port LC/UPC

Drawer housing

Drawer housing, ensure to save space and elegant design
