xWDM type CWDM
Channel number 10
Supported wavelengths 1270-1450
Multiplexer type DEMUX
Connector type SC/APC
Length mm 215
Height mm 20
Depth mm 213
weight 0,32
Operating temperature -5|70
Transmission type Simplex
Mounting type Chassis
Chassis type GBC Drawer
Insertion Loss ˂3.5 dB
Return Loss ˃45 dB
10 channels Simplex CWDM Demux in „drawer”, 10 CWDM channels: 1270-1450nm

Simplex demultiplexer with 10 CWDM ports

GBC Photonics has passive demultiplexers which allow to increase capacity of optical cables by adding multiple transmissions. Thanks to top-notch CWDM filters demultiplexers have low insertion loss and high channel isolation. Drawer housing allow to save space, using dedicated chassis we can place up to 4 drawer devices in 1U.

GPCDS100SASA2745NDSS Demultiplexer allows to launch 5 transmissions using a single fiber. Device has CWDM filters all in II transmit window. Demultiplexer has SC/APC ports.

Ports

10 ports SC/APC on CWDM lambdas 1270 - 1450 nm, Upgrade ports SC/APC, line port SC/APC

Drawer housing

Drawer housing, ensure to save space and elegant design
