xWDM type CWDM
Channel number 8
Supported wavelengths 1470-1610
Multiplexer type MUX
Upgrade port 1 1260 ~ 1457 nm
Monitor port 1
Connector type SC/APC
Length mm 215
Height mm 20
Depth mm 213
weight 0,3200
Operating temperature -5|70
Transmission type Simplex
Mounting type Chassis
Chassis type GBC Drawer
Insertion Loss ˂3.0 dB
Return Loss ˃45 dB
8+1 channels Simplex CWDM Mux in „drawer”, 8 CWDM channels: 1470-1610nm + UP: 1260~1457nm and MON Port

Simplex multiplexer with 8 CWDM ports and upgrade port

GBC Photonics has passive multiplexers which allow to increase capacity of optical cables by adding multiple transmissions. Thanks to top-notch CWDM filters multiplexers have low insertion loss and high channel isolation. Drawer housing allow to save space, using dedicated chassis we can place up to 4 drawer devices in 1U.

GPCMS081SASA4761MDSS Multiplexer allows to launch 4 transmissions in CWDM technology using a single fiber and with upgrade port on II transmit window we can easily expand capabilities of device. Multiplexer has SC/APC ports and built-in monitor port which allows to check upstream power on working transmissions.

Ports

8 ports SC/APC on CWDM lambdas 1470 - 1610 nm, Upgrade ports SC/APC, monitor port SC/APC, line port SC/APC

Monitor Port

Built-in monitor port allows to check 1% of upstream power

Upgrade Port

Single Upgrade port with wide band UP1: 1260 - 1457 nm

Drawer housing

Drawer housing, ensure to save space and elegant design
